Insulfix Track - Single

IconIcon

Insulfix Track - Single

L: 2400mm x W: 51mm x H: 130mm

  • In Stock
  • Product Code: R130S
Product Overview

Insulfix Track - Single provides a quick, easy and reliable way to correctly install insulation between single rafters. It can be used when installing boards from Inside the Roof and Outside the Roof.

Discounts Available:
  • From 1 to 9 lengths = £14.88 each (ex VAT)
  • 10 to 200 lengths = £13.40 each (ex VAT)
  • Orders over 200 lengths = please contact us

£14.88 Ex VAT

Secure payment powered by
Master Card Maestro Card Visa Card
+ READ TECHNICAL INFORMATION
Insulfix Ltd

How to Install Insulfix Track

Insulfix Track itself is very easy to install – just place over the rafter from above or underneath and fix with the recommended nails or screws using the fixing pattern.

Install Guide
Maximise Insulation & Minimise Waste

Typical waste savings based on rafters with 600mm centres and 2400mm x 1200mm insulation board  with 100mm x 2400mm offcuts cut to 4 X 550mm x 100mm & fitted into Insulfix Track.

With Insulfix Track

75%Saving in fitting time is possible
7.6%More board used
91.7%Less offcut waste
3.7Years estimated payback time

Details of the studies can be provided to back up the claims.

Key Benefits

  • Allows quicker and easier fixing of rigid insulation between rafters
  • Locks the insulation boards in place to minimise the gaps that can affect both the U-value and air-tightness performance of the insulated roof.
  • Allows more of the insulation boards to be used as the ‘off-cuts’ can be pushed into the track and stay firmly in place rather than being thrown in the bin.
  • Prevents boards from falling out after installation should the timber or insulation move or shrink over time.
  • Reduces the need to use expanding foam to fill gaps or to ‘foam-in’ the insulation.
  • Ensures a constant ventilation gap remains between the insulation boards and the roof covering.
  • As the insulation boards lock into the Track, they provide more load resistance than a friction-fitted option and provide an added element of confidence to the installer.
Insulfix Track - Single 1
